intAct Traktion-Power Deepcycle AGMRobust and enduring

AGM-based for high currents and deep charge cycles.
Our recommendation if you want an enduring, absolutely maintenance-free battery for electric vehicles or lifting platforms.

Very high life expectancy. 700 cycles according to IEC 254-1 for heavy cyclic use.
Absolutely maintenance-free. VRLA battery with gas recombination and safety valves, where refilling is not possible and not necessary.
Constant power quality throughout the discharge process even at high currents.
Longer life than wet lead-acid battery.
Shorter charging time than wet lead-acid battery.
Low self-discharge. Loses less than 3% charge per month.
Vibration resistant AGM battery with robust grids and strong fleece separators.
Reinforced grid plates with higher performance active material for deep cycle applications.
Temperature and corrosion resistant case.
Can also be installed horizontally.
Leak-proof.

Product overview

Cards
Detailed listing

Table
Compact overview

DC06-185AGM-S

Voltage	6V
Capacity	185 AH (c5), 200 AH (c20), 230 AH (c100)
Position of terminal	0
Size (LxWxH)	262x181x281mm

DC06-220AGM-S

Voltage	6V
Capacity	220 AH (c5), 260 AH (c20), 278 AH (c100)
Position of terminal	0
Size (LxWxH)	262x181x281mm

DC06-300AGM-S

Voltage	6V
Capacity	300 AH (c5), 315 AH (c20), 357 AH (c100)
Position of terminal	0
Size (LxWxH)	312x180x359mm

DC08-170AGM-S

Voltage	8V
Capacity	170 AH (c5), 185 AH (c20), 199 AH (c100)
Position of terminal	0
Size (LxWxH)	262x181x281mm

DC12-45AGM

Voltage	12V
Capacity	45 AH (c5), 52 AH (c20)
Position of terminal	3
Size (LxWxH)	224x120x175mm

DC12-54AGM

Voltage	12V
Capacity	54Ah c5, 60Ah c20
Position of terminal	3
Size (LxWxH)	224x135x178mm

DC12-70AGM-S

Voltage	12V
Capacity	70 AH (c5), 80 AH (c20), 99 AH (c100)
Position of terminal	1
Size (LxWxH)	260x171x210mm

DC12-85AGM-S

Voltage	12V
Capacity	85 AH (c5), 95 AH (c20), 107 AH (c100)
Position of terminal	1
Size (LxWxH)	260x171x210mm

DC12-110AGM-S

Voltage	12V
Capacity	110 AH (c5), 114 AH (c20), 136 AH (c100)
Position of terminal	1
Size (LxWxH)	329x171x215mm

Batterie	Voltage	Capacity	Length	Width	Height	Position of terminal	Endpolart	Datasheet
DC06-185AGM-S	6V	185 AH (c5), 200 AH (c20), 230 AH (c100)	262	181	281	0	F-M8	PDF
DC06-220AGM-S	6V	220 AH (c5), 260 AH (c20), 278 AH (c100)	262	181	281	0	F-M8	PDF
DC06-300AGM-S	6V	300 AH (c5), 315 AH (c20), 357 AH (c100)	312	180	359	0	F-M8	PDF
DC08-170AGM-S	8V	170 AH (c5), 185 AH (c20), 199 AH (c100)	262	181	281	0	F-M8	PDF
DC12-45AGM	12V	45 AH (c5), 52 AH (c20)	224	120	175	3	F-M5	PDF
DC12-54AGM	12V	54Ah c5, 60Ah c20	224	135	178	3	F-M5	PDF
DC12-70AGM-S	12V	70 AH (c5), 80 AH (c20), 99 AH (c100)	260	171	210	1	F-M8	PDF
DC12-85AGM-S	12V	85 AH (c5), 95 AH (c20), 107 AH (c100)	260	171	210	1	F-M8	PDF
DC12-110AGM-S	12V	110 AH (c5), 114 AH (c20), 136 AH (c100)	329	171	215	1	F-M8	PDF

Features

Power stable drive battery
AGM technology ensures consistent power quality throughout the discharge process, even at high currents and low charge.
Your benefit: Powerful traction battery for electric vehicles, hybrids as well as lifting platforms and cleaning machines.
Very durable
This battery has significantly thicker grid plates and reinforced fleece separators. Even at high loads, low temperatures and low charges, the performance remains stable.
Your advantage: Significantly more durable than a common grid plate battery.
Absolutely maintenance-free and leak-proof
This battery can also be operated safely lying on water.
Your advantage: You do not need to worry about water level control and refilling.

Knowledge

The desired application, different technologies, the required performance and your own requirements are just a few factors. We help you to keep an overview and find the right solution.

Knowledge

What is a GEL battery?

You've heard of GEL batteries, but you're wondering what makes them so special and whether they're the right choice for your vehicle or application? Don't worry, we'll enlighten you!

What is a GEL battery

Knowledge

What is an AGM battery?

Are you looking for a battery with strong performance and a long service life? Then the AGM battery is just right for you! Find out more about its advantages and areas of application here.

What is an AGM battery
